Hard-lying hyperbaric oxygen chamber,1.0-1.6ATA adjustable pressure, mild and safe for home care.
√ The In-Out Control system of Macy Pan 1501 allows you to operate the chamber yourself, with no assistance required.
√ Power Failure Safety System will release pressure automatically when the power shuts off.
√ An efficient Cooling System reduces humidity and cooling air to offer a comfortable user experience.
√ Anion Air Purification System for effective dispersion of anions to offer a cleaner and fresher environment..
√ Equip with a Door Close Sensor lock to sense if the door is fully closed, which is safer.
√ Timing system. The use of time can be preset in advance.
1. Slide type entry door with wide and convenient transparent viewing window.
2. Easy operation: One people can operate it without assistance.
3. Interphone system for two-way communication.
4. Automatic air pressure control system.
6. Automatic digital display technology to show data like pressure, purity, humidity and temperature.
7.Delivers 93% oxygen under pressure via an oxygen headset/facial mask.Easy installation and operation.
- Pressure: 1.5/1.6ATA, safe and suitable pressure, not high to harm our body, not low less effective.
- Size: 88inch(Length)*30inch(Diameters), big enough space for patients to have a comfortable using experience.
- A complete unit includes TWO parts only, Chamber Cabin+All-In-One Machine(oxygen concentrator+air compressor+air cooler), design idea for more easy operation by clients.
- Digital Display Screen to display data automatically like Temp, Pressure, Oxygen Purity, Humidity etc.
- A large transparent door allows more view to feel more peaceful, no panic.
- Eye Protection Type LED Light to protect elders as possible as we can.
- Chamber outside Phone Communication System allows patients inside can talk with outside.
- Chamber Inside ONE-BUTTON Communicating System allows patients can call outside for service or emergency situation.
- Internal Pressure Gauge, so patient inside can see pressure increasing and reducing when doing oxygen therapy, more safe to use, and feel no panic.- Timer design, people can set a treatment session at any ideal time they want from 0-120 minutes.
- Special Air Pump Power Design for Door so people can close and open the door even with one finger, which we are proud of it.
-Wheels on whole unit so people can move it easily to place they want to locate.
Model | HP1501 | |
chamber cabin | Pressure | 1.5-1.6 ATA |
Material | Stainless steel + Polycarbonate | |
Size | 220*75*75cm / 87*30*30” | |
Weight | 140KG | |
System Machine | Size | 76*45*65cm / 30*18*26“ |
Weight | 80KG | |
Flow of Air | 72 Liter/Min | |
Flow of Oxygen | 10 Liter/Min | |
Air Filter | Dual | |
Voltage | 110/220 VAC ±10% | |
Description | All-in-one machine, a combine of air compressor,oxygen | |
Oxygen Concentrator | Size | 47*46*69cm / 18*18*27“ |
Flow Rate | 10Liter/min | |
Description | 28KG | |
Air Conditioner | Size | 47*46*69cm / 18*18*27“ |
Weight | 35KG |
About Delivery
Worldwide delivery with door to door service by sea/airpress/train
MACY-PAN supplies a complete system of hyperbaric chambers, including a hyperbaric capsule, oxygen concentrator, air compressor, and optional air cooler, no need to buy anything else.
The largest range of Hyperbarics, including soft sitting/lying, hard sitting/lying, single-people/ multi-people, wheelchair chamber from 1.0-2.0ATA
Works under ISO 13485 / ISO 9001 / CE / SGS, Environment Friendly Material NON-Glue, NON-Toxic.
Designed for patients to easily self-treat, devoted to providing quality and brilliantly safe hyperbaric chambers to physicians, professional athletes, wellness centers and families.
Export experience in more than 123 countries with 10000+ clients
Latest technology to deliver the MOST effective therapy, with the highest efficiency and safety standards.
With environmental spray paint; Strong weight bearing capacity, up to 300kg; Durable and wear-resistant; Non-deformable; Long lifespan.Support for color customization.
In-Out Communication system allows the patient to communicate with the operator.
Patients can communicate with the operator in real-time or make pressure/time adjustments while enjoying oxygen therapy.
Prevents claustrophobia of the user and allows observation of the patient in the chamber through a window.
Patient be moved in and out via a sliding stretcher. Convenient for users who can't move or people with limited mobility.
The four most critical things about using a hyperbaric chamber are the following, which will relate to the effectiveness of your use, but of course can be adjusted by your own situation or doctor's advice.
Price includes chamber capsule/cabin, oxygen concentrator, air Compressor, air cooler, and all system components. You DO NOT need to buy/prepare anything else.
No. Our chambers are easy and safe to operate alone, with no need for other's assistance. Anyone with average studies can install and operate the chamber as long as reads the user manual and operation video. We provide customers with online training. Also, face-to-face talk is available.
People can go into the chamber fully clothed. It is recommended to wear loose comfortable. Shoes, jewellery, or any sharp objects should be removed before getting into the chamber. It is recommended that women not wear stockings in the chamber, because it may cause feelings of claustrophobia.
While the chamber is pressurizing, your ears will feel the change in pressure inside the chamber. Otherwise, it should be unnoticeable. To equalize the pressure and avoid the feeling of fullness in your ears, you will need to clear your ears by chewing(gum of food), swallowing, yawning. During the pressurization of the chamber, your mouth may become dry. Once the chamber is fully pressurized, your salivation will return to normal. Other than this ear pressure there are no unusual or different sensations. After using the oxygen chamber, one of the most intuitive feelings is refreshing, and you will feel full of vitality.
For students, oxygen supplementation has a good effect on eliminating fatigue, relieving examination pressure, and protecting the brain. For plateau hypoxic areas, the hypoxic state of the body can be corrected immediately, and the body's adaptability to the plateau can be enhanced. For middle-aged and elderly people, it can make up for the lack of oxygen supply caused by the decline of physiological function and improve self-healing ability. For athletes, it can relieve muscle fatigue, restore physical strength, and reduce sports injuries. For women, supplementing oxygen can enhance the metabolism of skin cells, reduce melanin, and beautify the skin. For office workers, it can enhance the blood oxygen diffusion capacity, thereby improving the body's hypoxia state. Fatigue decreased workability, fatigue, insomnia, loss of appetite, etc. can be relieved.
Usually for personal use, 60-90 min one time, one time one day, 5 days one week. What you will be able to notice is whether you are continuing to make improvements. A clinical study on 1730 subjects shows the need for around 15 sessions for acute injuries and 40 for chronic ones. If you saw results during the first 40 sessions, do another 40. If improvements continue, do another 40. Etc. You are a better judge of the number of sessions needed than any Doctor.
People who catch a cold or flu symptoms, people who have rhinitis or otitis media, and people who are pregnant should follow the doctor's advice to use the oxygen chamber.
The most common side effect is discomfort in the ears caused by pressure changes. To minimize the risk, patients learn to promote the adequate clearing of their ears during pressurization. Some patients may feel tired and dizzy after using a hyperbaric chamber for the first time. It's a good signal as Hyperbaric Oxygen Therapy will speed up the metabolism of our body. Just like people feel tired after a long running. They are usually good signs of indicating detoxification.
Oxygen Toxicity is not a problem at pressures below 1.5 ATA. Many times stress is mistaken for oxygen toxicity. Occasionally, there may be a patient who is more sensitive to Oxygen than others and pressures may need to be adjusted to meet the needs of the patient.
One year warranty and lifetime maintenance. If any quality problem/fault in material/design under correct operation within one year, if easy to fix, we will send new components Freely and guide you on how to repair them. If hard or complicated to fix, we will send a new chamber or machine to you directly and Freely. In this way, we won't need you to send back the machines, just video and pictures will be ok for our analysis. (shipping cost not covered.)
Pregnant women, people with infectious diseases and severe illnesses. Drunk. People with severe colds. Patients with pacemakers. Rhinitis, otitis media patients. People with high blood pressure exceeding 160/110 mmHg. Patients with severe emphysema.
Discount Price, ship by DHL, door to door service, 5-7days delivery time, local technical support
We supply soft and hard chambers from 1.3-2.0ATA to reach different customers' needs
Create custom uniquea hyperbaric chambers to reach your target market
We have more than 50 distributors around world, looking forward to having you on board.
